C10500 has high conductivity, thermal conductivity, corrosion resistance, moderate strength, and easy processing and formability. C10500 has better high-temperature softening resistance compared to pure copper. C10500 is widely used in automotive water tanks, heat sinks, motor commutators, relays, etc. It is also suitable for making lead frame materials for circuit chips, as well as special materials for motor commutators and lead frame materials.
| Grade | Chemical composition（%）≤ | |||
| GB | ASTM | Ag | Cu+Ag | O |
| TUAg0.03 | C10500 | 0.034 | ≥99.95 | ≤0.001 |
| Physical properties | |||||
| Density (g/cm³) |
Modulus of elasticity (GPa) |
Thermal expansion coefficient (×10-6/K) |
Electrical conductivity (%IACS) |
Thermal conductivity (W/(m·K)) |
|
| 8.94 | 115 | 17 | 100 | 391 | |
| Mechanical properties | |||||||
| Temper | Tensile Strength Rm/MPa |
Elongation % |
Hardness HV |
||||
| GB | ASTM | GB | ASTM | GB | ASTM | GB | ASTM |
| O60 | H00 | ≥195 | 200-275 | ≥30 | - | ≤70 | - |
| H01 | H01 | 215-275 | 235-295 | ≥25 | 60-90 | ||
| H02 | H02 | 245-345 | 255-315 | ≥8 | 80-110 | ||
| H03 | 285-345 | ||||||
| H04 | H04 | 295-380 | 295-360 | ≥3 | 90-120 | ||
| H06 | 325-385 | ||||||
| H06 | H08 | ≥350 | 345-400 | - | ≥110 | ||
| H10 | ≥360 | ||||||
